Transmission - ZF63C (#ZF63C)

**Specify Gear Ratio When Ordering**

DESCRIPTION

•**We currently have 1 in stock, 1:1 gear ratio, any other gear ratio is not currently available**
•Reverse reduction marine transmission with hydraulically actuated multi-disc clutches .
•Suitable for high performance applications skiboats and waterjets. .
•Fully works tested, reliable and simple to install .
•Design, manufacture and quality control standards comply with ISO 9001 .
•Compatible with all types of engines and propulsion systems, including waterjets and surface- piercing propellers, as applicable .
•Max input torque and power can not be transmitted when shifting lever is in position «B». «B» position in used only for reverse operation during docking and low speed maneuvering .

FEATURES

•Lightweight and robust aluminum alloy casing (sea water resistant) .
•Case hardened and precisely ground gear teeth for long life and smooth running .
•Output shaft thrust bearing designed to take maximum propeller thrust astern and ahead .
•B/W connection integrated with casing .
•Smooth and reliable hydraulic shifting with control lever for attachment of push-pull cable .
•Replaceable oil filter cartridge .
•The reversible oil pump makes the gearbox suitable for use with right hand or left hand rotation engine .

OPTIONS

•Engine-matched dual stage coupling .
•SAE 3 and SAE 4 bell housings .
•Oil cooler .
•Propeller shaft flange .
•Control cable bracket for mounting of push-pull cable to the control lever .
•Electric clutch control available (12 VDC) .
•Classification by all major Classification Societies on request .

Specifications (Open Link)
