3 Pole 250A C-Series Flat Rocker Circuit Breaker (BLUE SEA SYSTEMS P/N 7477) (#BS7477)
PRICE:
$173.22
Part #: BS7477
This product is no longer available.
- 3 Pole 250A C-Series Flat Rocker Circuit Breaker
- Paralleled poles have 5/16 in. stud on bus
- Rocker actuator is flush in the ON position eliminating the risk of accidental switching
- Color actuator indicates OFF position
- Provides overcurrent protection for inverters bow thrusters and windlasses
- Combines switching and circuit protection into a single device
- Trip Free cannot be held closed after trip
- Operating temperature range -40 degrees C to +85 degrees C
- Magnetic hydraulic circuit breaker type
- Rated switch cycles 10 000 @ rated amperage and voltage
- Terminal stud 1/4 in.-20 tin-plated brass?maximum torque 35 in.-lb.
- Mounting screw stainless steel #6-32 recommended torque 6-8 in.-lb.
- Case material phenolic
