New GM Longblock - 5.7L Vortec, 295hp, 1996-current Carb w/o crank position sensor (#2541-S)

Category Menu

New GM Longblock - 5.7L Vortec, 295hp, 1996-current Carb w/o crank position sensor (#2541-S)

PRICE: $2,595.00

Part #: 2541-S

Quantity:

Add this product to your cart to estimate shipping cost

**No core required**

This longblock is for GM Based Small V8 applications including Mercruiser, Volvo Penta, Crusader, Indmar, Marine Power, etc. There are various changes that were made on the 5.7L engine throughout the years. Select the following link that will assist you in choosing the correct longblock for you application. Technical Tips. This engine comes complete with all associated tin-ware (oil pan, valve covers, timing cover), they do not include the flywheel, balancer or water pump. These engines can easily be identified by the (8) bolts used to fasten the intake manifold to the cylinder heads.

NOTE: There is a provision for mechanical fuel pump on this engine. Therefore if you are currently using an electrical fuel pump you must get the fuel pump block off plate to cover this feature.

NOTE: It should be noted that the Vortec 5.7L longblocks are supplied WITHOUT a crank position sensor in the front timing chain cover. Therefore you must remove your existing crank position sensor and re-install it in the timing chain cover of the new longblock, otherwise the engine will leak oil out of this open hole. If your old engine did not utilize a crank position sensor you must purchase one to plug this hole as it requires this special o-ring type seal.

Type: 90° 5.7L V8

Displacement:350 cid(5736.50cc)

Compression Ratio: 9.4:1

Valve Configuration: Pushrod Actuated

Valve Lifters: Hydraulic Roller

Bore x Stroke: 4.00x

3.48in(101.60x88.39mm)

Main Bearing Caps: 2-Bolt Cast Iron

Balance Method: External

Horsepower:

295hp@5000 rpm (PFI)

Torque: 355 lb-ft@3600 rpm (PFI)

Materials:

Block: Cast Iron Intake Manifold: Customer Supplied

Firing Order: 1-8-4-3-6-5-7-2

Oil Pan Capacity: 5qt

Fuel Types: Gasoline (unleaded)

Engine Rotation: Clockwise (from the front)

Paint Protection: Component Painted

Shipping Weight: 500Lb

For more details about product installation, select the following link for details. Engine Installation Information ….

Includes an Up To 12 month limited warranty.

Upon completing any engine order on the website you will be sent a Purchase Sales Agreement which must be completed and returned before the engine will be shipped. This document contains important warranty information and protects both the seller and buyer for the purposes of the sale.

Correction to ISO 3046/SAE J1228. Actual power levels may vary depending on OEM calibration and application. Horsepower and torque numbers based on PFI Intake Manifold. Available at Ypsilanti PC&L.

All specifications, availability, and pricing listed are based on the latest product information available at the time of publication.The right is reserved to make changes at any time without notice.
